产品描述Product description
◆K2-2F系列是一款专用型的跷板开关，也通称船型开关、波形开关等，应用于种种电动工具和清洁器具，如：台锯、台式砂轮机、干湿两用吸尘器等，也同样适用于种种家用电器、仪器及办公设备等。
◆K2-2F series are one special type rocker switches, for used in power tools and cleaning appliances such as: Table Saws, Bench Grinders, Dry and Wet Vacuum Cleaners, etc. Also for used in all kinds of Home appliances, testing equipments and office equipments, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→双极双单掷 DPST (Double Pole Single Throw)
→双极双单掷点动 DPST momentary (Double Pole Single Throw)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4 / 1E5
→电气耐久寿命 Electrical life endurance≥1E4 / 5E4
→最大攻击电流 Max. Inrush current at 250V48A / 72A
→最大攻击电流 Max. Inrush current at 125V48A / 96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~105°C
→操动件温度 Actuator temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals
电气参数和认证 Electric Rating and Certification
