◆KND3系列是一款通用型的跷板开关，也通称船型开关、波形开关等，一般应用于种种电吹风、热风枪等。
◆KND3 series are one general type rocker switches, commonly for used in Hair Driers, Heat Guns, etc.
产品特征Features
◆可选差别的主体 Optional with different Body Types
◆可选多种差别的按钮 Optional with different Button Types
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V30A
→最大攻击电流 Max. Inrush current at 250V36A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~85°C
→操动件温度 Actuator temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
