产品描述Product description
◆JB01系列是一款大电流的宁静限位开关，集成防尘防水功效，JB010B为迷你款，适用于种种台式电动工具和园林工具，如：台式推拉锯、台式圆锯、台式刨床、台式铣床、台式车床、台式线锯、台式钻床和家用碎枝机等 。
◆JB01 series are high rated safety limited switches, integrated dustproof and waterproof, JB010B is mini-type, for used in bench top power-tools or gardening tools, such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Lathes, Bench Scroll Saws, Bench Drill Presses, Domestic Shredders, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→双极�？� DPNO?(Double Pole Normally Open)
→双极常闭?DPNC (Double Pole Normally Close)
◆可选带以下附件 Optional with the accessories as follows:
→钥匙扣 Key
→门控制杆 Handle for door
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4 / 1E5
→电气耐久寿命 Electrical life endurance≥1E4 / 5E4
→最大攻击电流 Max. Inrush current at 250V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP54 Max.
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆JB01输入端/输出端 Input side/Output side of JB01:
→螺钉端子 Screw terminals M4
◆JB01B输入端/输出端 Input side/Output side of JB01B:
→插片端子 Plug-in terminals 4.8×4.8mm
电气参数和认证 Electric Rating and Certification
