JB06-10/1

JB06/JB08旧款电动工具专用开关

JB06/JB08 series Switches Special for Previous Type Power-tools

产品描述Product description

◆JB06系列是一专用的旧款机型开关 ，集成防尘功效 ，适用于手持式电动工具 ，如：电钻、电锤、往复锯、马刀锯、曲线锯、角磨机、搅拌器、砂光机等 。
◆JB06 series are one special type switch for previous type power-tools, integrated dustproof, for used in portable power-tools, such as Electric Drills, Rotary Hammers, Reciprocating Saws, Sanders, Sabre Saws, Jig Saws, Electric Mixers, Angle Grinders, etc.

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端 Inpust side:
→接线柱端子 Pillar terminals φ=3mm
◆输出端 Output side:
→插入式端子可插入插片端子2.8×0.8mm
→Push-in terminals for plug-in terminals 2.8×0.8mm

电气参数和认证 Electric Rating and Certification
