产品特征Features
◆可选带以下功效 Optional with the function as follows:
→双极�？� DPNO (Double Pole Normally Open)
→一极常闭，另一极�？� One Pole Normally Close, the other Normally Open
→一极常闭，另二极�？� One Pole Normally Close, the other two poles Normally Open
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4/1E5
→电气耐久寿命 Electrical life endurance≥1E4/5E4
→最大攻击电流 Max. Inrush current at 250V96A
→最大攻击电流 Max. Inrush currentat 125V120A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
