BC-04

BC电池夹

BC series Battery Clamp

产品描述Product description

◆BC系列是专用型的直流电池夹 ，应用于种种直流电池式手持电动工具 ，如：充电式电钻、充电式螺丝起子等 ，可凭据种种要求进行定制 。
◆BC series are special type DC battery clamp, for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, etc. We can make customized according to different request.

产品特征Features

◆质料：锡青铜 Material: Tin-bronze
◆外貌处理：镀镍 surface treatment: Nickel Plated

技术数据Technical data

→机械耐久寿命 Mechanical life endurance

≥1E4→最大电流 Max. current at 42Vd.c25A
→接触电阻 Contact resistance≤30m Ohm

→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0

端子类型Terminals

◆输入端 Input side:
→焊接端子 Soldering terminal

电气参数和认证 Electric Rating and Certification
