产品描述Product description
◆MK04系列是一款专用型的交流线路板组件，具有软启动等功效，广泛应用于种种手持式电动工具，如：150和180角向磨光机、抛光机、型材切割机、斜切锯等 。
◆MK04 series are one special type AC PCB Assembly, with soft start function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Polisher Grinders, Cut-off machines or Miter Saws, etc.
产品特征Features
◆可选带以下功效 Optional following function types:
→断电重启�；すπ� Restart Protection(X)
→软启动功效 Soft Start Function(S)
→过流�；すπ� Over Current Protection Function(CP)
→过温�；すπ� Over Temperature Protection Function(TP)
技术数据Technical data
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 250V15A
→最大电流 Max. current at 127V24A
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature-0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→导线端子 Wire lead terminals
电气参数和认证 Electric Rating and Certification
