产品描述Product description
◆MK08系列是一款专用型无刷电机控制器(线路板组件)，具有调速，LED灯电量显示、功效切换等功效，广泛应用于种种直流无刷充电式手持式电动工具，如：无刷充电扳手、无刷充电电钻等。
◆MK08 series are one special type Controller (PCB Assembly) for DC brushless motor, integrated with Speed control, LED battery remaining display, function switching, etc. Commonly for used in brushless DC portable power-tools such as DC Brushless Impact Wrench, DC Brushless Drill, etc.
产品特征Features
◆可选带以下功效 Optional following function types:
→电子调速功效 Electronics Speed Control Function
→LED灯电量显示 LED battery remaining display
→功效切换 Function switching
技术数据Technical data
→电气耐久寿命 Electrical life endurance≥3E5
→最大电流 Max. current at 42Vd.c25A
→绝缘电阻 Insulation resistance≥7M Ohm
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端 Input side:
→导线端子 Wire lead terminals
→信号端-专用插座 Single-Socket
◆输出端 Output side:
→焊接端子 Soldering terminals 6.3×0.8
电气参数和认证 Electric Rating and Certification
