◆DR2-6E系列是一款通用型的转盘电子调速器 ，是FR-6E系列的迷你版本 ，应用于种种手持电动工具 ，如：电锤、曲线锯、往复锯、100和125角向磨光机、,抛光机、搅拌器、电木铣、砂光机、模具电磨等。
◆DR2-6E series are one general type AC Dial Wheel Speed Controls, the mini-type of FR-6E series, for popular used in portable power-tools such as: Rotary Hammer, Jig Saws, Reciprocating Saws, 100mm and 125mm Angle Grinders, Polisher Grinders, Electric Routers, Sanders, Die Grinders, etc.◆可选带以下功效 Optional with following function:
→全波调速 Full-wave s peed control
→半波调速 Half-wave speed control
→On-Off通断功效带可变电阻输出 On-off version with Passive linear potentiometer
◆可选带以下附件 Optional with the accessories as follows:
→初始电压微调理旋钮 Knob for adjusting start voltage
→可控硅外置适合更大电流并可附带散热片
→External Triac version for high currents additional with heat sink
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical lifeendurance≥5E4
→最大电流 Max. current at 250V8A
→最大电流 Max. current at 125V12A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 Flammability UL 94V-0
→防护品级 Protection type IP40
→开关内部电子部分在相应使用中一并做过相关测试 ，本开关适合做二类器具开关使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
◆输入端/输出端 Input side/Output side:
→导线端子 Wires terminals AWG14 ~ AWG18.
