DEK series Dustproof (Multi-function) DC Variable Speed Trigger Switches
产品描述Product description
◆DEK系列是一款通用型的直流扳机调速开关，集成防尘和机械刹车接点，内部带换向结构，应用于种种直流充电式手持电动工具，如:充电式电钻、充电式电锤、充电式螺丝起子、充电式攻击扳手等.
◆DEK series are one general type DC variable speed trigger switches, integrated dustproof, mechanical brake contact and reversing box, commonly for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, etc.
产品特征Features
◆本开关结构紧凑效率高,大面积的牢固式散热片为开关的装置提供便当.开关内部为单极�？蓖ń拥憬峁�,通过改变输入脉冲的占空比来控制场效应管的输出电压，而实现电子调速功效. ◆开关输出端的平均电压为总电压的8-50%至8-90%,也可以按客户要求进行定制,开关按究竟由直通接点接至电池端电压. ◆可选带以下功效或附件: →外置MOS管 →带软胶扳机 →外接LED及导线 →外接电池温度检测导线 →智能调速功效,可带软启动,欠压�；�,过流�；�,电池过温�；� ◆The switches combine compact size with high performance, a wide scope of heat sink for MOSFET and further options provide easy to mount solutions. They employ SPST-NO with by-pass contact, integrated PWM (Pulse Width Modulated) electronics in various dimensions. ◆Average duty cycle of motor voltage 8 - 50% to 8 - 99%, then by-pass to battery voltage (according to customer's demand). ◆Optional with the function or accessory as follows:
→External MOSFET version
→Trigger covered with rubber
→Auxiliary LED and wires
→Auxiliary wire for temperature test
→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature protection
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 42Vd.c 25A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric strength of reinforced500V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
