产品特征Features
◆本开关结构紧凑效率高 ，大面积的牢固式散热片为开关的装置提供便当 �？啬诓课ゼ？蓖ń拥憬峁� ，通过改变输入脉冲的占空比来控制场效应管的输出电压 ，而实现电子调速功效 。
◆开关输出端的平均电压为总电压的8- 50%至8- 90% ，也可以按客户要求进行定制 ，开关按究竟由直通接点接至电池端电压 。
◆可选带以下功效或附件：
→外置MOS管
→外接发光LED及导线
◆The switches combine compact size with high performance, a wide scope of heat sink for MOSFET and further options provide easy to mount solutions. They employ SPST-NO with by-pass contact, integrated PWM (Pulse Width Modulated) electronics in various dimensions.
◆Average duty cycle of motor voltage 8 - 50% to 8 - 90%, then by-pass to battery voltage (according to customer's demand).
◆Optional with the function or accessory as follows:
→Extrenal MOSFET version
→Auxiliary LED and wires
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命 Electrical life endurance≥1E4
→最大电流 Max. current at 36Vd.c25A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric streng th of reinforced500V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, So the switches are suitable for appliance of class II .
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→焊接端子 Solder terminal 48X0.8mm
