产品特征Features
◆本开关结构紧凑，可选带以下功效或附件：
→电子调速功效
→智能调速功效，可选带软启动、欠压�；ぁ⒐鞅；ぁ⒌绯毓卤；さ�
→外接种种导线和电池夹
◆The switches combine compact size, optional with the function or accessories as follows:
→Electronics variable speed control function
→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature protection, etc.
→Auxiliary wire or battery clamp
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4/1E5
→电气耐久寿命 Electrical life endurance≥1E4/5E4
→最大电流 Max. currentat 18Vd.c20A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7MOhm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric strength of reinforced500V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端 Input side:
→焊接端子 Solder terminal 4.2×0.8mm
◆输出端 Output side:
→焊接端子 Solder terminal4.6×0.5mm
