产品描述Product description
◆DPK-S系列是一款通用型的直流信号扳机开关，集成防尘功能，内部带换向结构，特别应用于种种直流无刷充电式手持电动工具和园林工具，如：无刷充电式电钻、无刷充电式电锤、无刷充电式螺丝起子、无刷充电式攻击扳手、无刷充电式打草机、无刷充电式吹风机等 。
◆DPK-S series are general type DC signal trigger switches,integrated dustproof and reversing box, specially for used in DCcordless brushless portable power-tools and gardening tools such as: Cordless brushless Drills, Cordless brushless Screw Drivers, Cordless,Rotary Hammers, Cordless brushless Impact Wrenches,Cordless brushless grass trimmer, Cordless brushless blowers,etc.
产品特征Features
◆可选带以下功效或附件:
→信号通断带电位器输出功效
→信号通断带正反转信号和电位器输出功效
→信号通断带正反转霍尔信号和电位器输出功效
→霍尔信号通断带正反转霍尔信号和霍尔电位器输出功效
→可选带闭合锁定
→带软胶扳机
◆Optional with the function or accessory as follows:.
→On-off with linear potentiometer
→On-off with Reversing Signal and linear potentiometer output
→On-off with Reversing Hall Signal and linear potentiometer output
→Optional with Lock-on button
→Trigger covered with rubber (overmolding)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current0.1A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→带插头导线 Wire terminal with Plug
★本产品荣获实用新型专利，专利号：ZL201922328152.5
★Utility Model patented with the no. is?ZL201922328152.5
电气参数和认证 Electric Rating and Certification
