产品描述Product description
◆FA01系列是一款通用型的直流扳机调速开关 ，集成防尘和机械刹车接点 ，可选带换向盒 ，应用于种种直流充电式手持电动工具 ，如：充电式电钻、充电式螺丝起子等 ，也可用于充电式钻骨机、充电式胸骨锯、充电式摆锯等直流医疗器械。
◆FA01 series are one general type DC variable speed trigger switches, integrated dustproof and mechanical brake contact, optional with reversing box, for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, etc. Also special for used in DC medical tools, such as Cordless Bone Drills, Cordless Sternum Saws, Cordless Overhaul Saws, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→电子调速功效 Electronics Speed Control function
→通断功效 On-off version
→通断功效带电位器输出 On-off with linear potentiometer output
◆可选带以下附件功效 Optional with the accessories as follows:
→MOS管散热片 Heatsink for MOSFET
→包软胶扳机Trigger covered with rubber (Overmolding)、
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命E lectrical life endurance≥1E4
→最大电流 Max.current at 36Vd.c16A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Dielectric strength of reinforced500V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试 ，本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端/输出端 Input side/ Output side:
→插入式端子 Push-in terminal
→导线端子 Wire terminal
电气参数和认证 Electric Rating and Certification
