产品描述Product description
◆FA1-6A系列是一款通用型的扳机开关，应用于对防尘要求较低的手持式电动工具和园林工具，如：搅拌器、电动钉枪、电圆锯、打草机、电链锯、电动割草机、电动扫雪机等。
◆FA1-6A series are general type trigger switch, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Circular Saws, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
产品特征Features
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 NoLock
→闭合锁定 Lock-on
→断开锁定 Lock-off
◆可选带以下附件 Optional with the accessories as follows:
→双联动按钮Button with double linkage action
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max.Inrush current at 250V60A
→最大攻击电流 Max.Inrush currentat 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端 Input side:
→2×接线柱端子 Pillar terminals φ=2.6mm or 2.8mm
→4×插入式端子可插入沾锡导线、带插片端子导线或铜包头导线
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
◆输出端 Output side:
→2×接线柱端子 Pillar terminals φ=2.6mm or 2.8mm
→4×插入式端子可插入沾锡导线、带插片端子导线或铜包头导线
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
电气参数和认证 Electric Rating and Certification
