产品描述Product description
◆FA2-6A系列是一款通用型的扳机开关，集成防尘功效，广泛应用于种种手持式电动工具，如：电钻、云石机、电圆锯、电木铣、砂带机，砂光机、电刨等 。
◆FA2-6A series are one general type trigger switch, integrated dustproof, commonly for used in portable power tools such as Electric Drills, Marble Cutters, Circular Saws, Electric Routers, Belt Sanders, Electric Planers, etc.
产品特征Features
◆可选带以下功效 Optional with following function:
→单极�？� SPNO
→一极�？�，另一极直通 One Pole NO, the other Connected
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Diele ctric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→螺钉端子 Screw terminals M3.5
电气参数和认证 Electric Rating and Certification
