产品描述Product description
◆FA2-6AN系列是一款通用型的扳机开关，为FA2-6A系列的防尘革新款，广泛应用于种种手持式电动工具和园林工具，如：电钻、云石机、电圆锯、电木铣、砂带机、砂光机、电刨、电链锯等 。
◆FA2-6AN series are one general type trigger switch, which is dustproof improved version of FA2-6A series, commonly for used in portable power tools and gerdening tools such as Electric Drills, Marble Cutters, Circular Saws, Electric Routers, Belt Sanders, Electric Planers, Electric Chain Saw, etc.
产品特征Features
◆可选带以下功效 Optional with following function:
→单极�？� SPNO
→一极�？�，另一极直通 One Pole NO, the other Connected
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M? Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Diele ctric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→螺钉端子 Screw terminals M3.5
电气参数和认证 Electric Rating and Certification
