产品描述Product description
◆FA2-6BN系列是一款通用型的扳机开关, FA2-6B系列的防尘革新款，广泛应用于种种电动工具，如：型材切割机、斜切锯、电圆锯、电锤、电镐等 。
◆FA2-6BN series areone general type trigger switch, which is dustproof improved version of FA2-6B series, commonly for used in power tools such as Cut-off Machines, Miter Saws, Circular Saws, Ele ctric Hammers, Demolition Hammers, etc.
产品特征Features
◆可选带以下功效 Optional with following function:
→单极�？� SPNO
→单极双掷 SPDT
→一极�？�，另- -极直通 One Pole NO, the other Directly
→一极双掷，另一极直通 One Pole DT, the other Directly
◆可选带以下附件 Optional with the accessories as follows:
→包软胶扳机 Trigger covered with rubber (overmolding)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 125V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.0mm
电气参数和认证 Electric Rating and Certification
