产品描述Product description
◆FA7-10C系列是FA7-10系列的防尘革新款，内部为快速行动结构，内部具有良好的防尘性能，应用于对防尘要求较高的电动工具和园林工具，如：电圆锯、曲线锯、抛光机、电锤、电镐、型材切割机、斜切锯等。
◆FA7-10C series are updated type of FA7-10 series, with snap-action structure, integrated high grade dustproof, for used in power-tools and gardening tools such as Circular Saws, Jig Saws, Polishers Grinders, Rotary Hammers, Demolition Hammers, Miter Saws, Cut-off Machines, etc.
产品特征Features
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
◆可选带以下功效或附件 Optional with following function or accessories:
→双极� ？� DPNO
→单极� ？� SPNO
→一极� ？�，另一极常闭 One Pole Normally Open, the other normally close
→带软胶扳机Trigger covered with rubber (Overmolding)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max.Inrush current at 250V90A
→最大攻击电流 Max. Inrush current at 127V120A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.5mm
★本产品荣获实用新型专利，专利号：ZL201920475212.3
★Utility Model patented with the no. is ZL201920475212.3
电气参数和认证 Electric Rating and Certification
