产品描述Product description
◆FA7-10D系列是一款通用型的扳机开关，应用于对防尘要求较低的手持式电动工具和园林工具，如：搅拌器、电动钉枪、电圆锯、打草机、电链锯、电动割草机、电动扫雪机等 。
◆FA7-10D series are general type trigger switch, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Circular Saws, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
产品特征Features
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V90A
→最大攻击电流 Max. Inrush current at 125V108A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.5mm
电气参数和认证 Electric Rating and Certification
