FA2-5DN-2115

FA2-5DN快速行动防尘按钮开关

FA2-5DN Snap-action Dustproof Push-button Switches

产品描述Product description

◆FA2-5DN系列是一款专用型的按钮开关，集成防尘功效，内部为快速行动结构，应用于种种手持式电动工具，如：125和150角向磨光机、抛光机等。
◆FA2-5DN series are special type Push-button switch, integrated dustproof, with snap-action structure, for used in portable power-tools such as 125mm and 150mm Angle Grinders, Polishers Grinders, etc.

产品特征Features

◆可选带以下附件 Optional with the accessories as follows: .
→滤波电容(电容值由客户选定，一般为0.22μF或0.33μF)
→Suppression capacitor (commonly 0.22or 0.33μF)

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 127V90A
→最大电流 Max. current at 42Vd.c30A
→最大电流 Max. current at 24Vd.c40A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强 度Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端 Input side:
→螺钉端子 Screw terminals M3.5
◆输出端 Output side:

→插片端子 Plug-in terminals 4.8×0.8mm

→焊接端子 Plug-in terminals 4.8×0.8mm

→电容插片端子 Plug-in terminals for capacitor 2.8×0.8mm
★本产品荣获实用新型专利，专利号：ZL202020005964.6
★Utility Model patented with the no. is ZL202020005964.6

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
