FA7-6B-2L16

FA7-6B防尘按钮开关

FA7-6B series Dustproof Push-button Switches

产品描述Product description

◆FA7-6B系列是一款专用型的按钮开关，集成防尘功效，应用于种种手持式电动工具，如：电木铣、修边机等，可选带闭合自锁功效。
◆FA7-6B series are special type Push-button switch, integrated dustproof, popular for used in portable power-tools such as Electric Routers, etc. Optional with self-lock function.

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端 Input side:
→接线柱端子 Pillar terminals φ=3mm
◆输出端 Output side:
→接线柱端子 Pillar terminals φ=3mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
