产品描述Product description
◆FA7-6J系列是一-款专用型的按钮开关，应用于手持式电动工具或小家电，如：电动钉枪、电吹风等。
◆FA7-6J series are special type push-button switch, for used in portable power tools or small appliances such as Electric Tackers, Hair Driers, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→单极�？� SPNO (Single Pole Normally Open)
→单极双掷 SPDT (Single Pole Double Throw)
→单极常闭 SPNC (Single Pole Normally Close)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4/1E5
→电气耐久寿命 Electrical life endurance≥1E4/5E4
→最大电流 Max. current at 250V10A
→最大电流 Max. current at 125V16A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~85°C;
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→焊接端子 Soldering terminals
电气参数和认证 Electric Rating and Certification
