◆FDC系列是一款专用型的倒扳开关，也叫摇杆开关或拨动开关，应用于种种电动工具，如：电木铣、台式砂轮机等 。 ◆FDC series are one special type Lever switch, for used in power-tools such as Routers, Bench Grinders, etc.
产品特征Features
◆可选带以下功效 Optional with following function: →单极单掷 SPST (Single Pole Single Throw) →单极双掷 SPDT (Single Pole Double Throw)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5 →电气耐久寿命 Electrical life endurance≥5E4 →最大攻击电流 Max.Inrush current at 250V60A →最大攻击电流 Max.Inrush current at 127V96A →接触电阻 Contact resistance≤30m Ohm →绝缘电阻 Insulation resistance≥7M Ohm →基本介电强度 Dielectric strength of function1500V →增强介电强度 Dielectric strength of reinforced3000V →情况温度 Ambient temperature0°C~55°C →阻燃品级 FlammabilityUL 94V-0 →防护品级 Protection typeIP40 →适用于II类防护器具 Suitable for appliances of protection class II
