◆FDJ, FDM系列是迷你型的小型推拉开关，也叫滑动开关，应用于种种需要微电流档位控制的电器，如：迷你型螺丝起子、充电灯等。
◆FDJ, FDM series are mini type slide switches, commonly for used in micro current appliances such as Mini Screwdrivers, Rechargeable Lights, etc.
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命 Electrical life endurance≥1E4
→最大电流 Max. current6A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→增强介电强度 Diele ctric strength of reinforced500V
→情况温度 Ambient temperature0°C~85°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection type IP40
→适用于II类防护器具 Suitable for appliances of protection class II
