FDU系列是一款专用型的滑动并关，也可推拉并关或推拨并关，应用于汽油动力园林工具，如：汽油动力打草机、汽油动力吹吸机、汽油动力链锯等。 FDU series are speciai typesiideswitches, commonly forusedin Power Gardening tools, such as Power Grass Trimmer, Power Blowers, Power Chain-saws, etc.
产品特征Features
可选带以下功效 Optional with following function:
→单极单掷 Single Pole Single Throw
→单极单掷点动 Single Pole Single Throw with momentary act
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4 →电气耐久寿命 Electrical life endurance≥1E4 →最大攻击电流 Max. Inrush current at 250V2A →最大攻击电流 Max. Inrush current at 125V4A →接触电阻 Contact resistance≤30m Ohm →绝缘电阻 Insulation resistance≥7M Ohm →基本介电强度 Dielectric strength of function500V →增强介电强度 Dielectric strength of reinforced500V →情况温度 Ambient temperature0°C~85°C →阻燃品级 FlammabilityUL 94V-0 →防护品级 Protection typeIP40 →适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
输入端/输出端 lnput side/Output side:
→插片端子 Plug terminals 6.3×0.8mm
→插片端子 Plug terminals 4.8×0.8mm
电气参数和认证 Electric Rating and Certification
