◆FDW系列是一款专用型的滑动开关 ，也可推拉并芙或推拨并关 ，应用于小电流的电动工具或家用电器上 ，如：直流充电电钻、烫发器等 。
◆FDW seriesarespeciai typesiidesWitches, commoniy forusedin Low current Power-tools or home appliances, such as DCCordless Drill, Hair iron, etc.
产品特征Features
◆可选带以下功效 Optional with following function:
◆单极三档位Single Pole 3 Position (SP3P)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命E lectrical life endurance≥5E4
→最大电流 Max. current at 250V4A →最大电流 Max. current at 127V8A →接触电阻 Contact resistance30m Ohm
→绝缘电阻 lnsulation resistance7M Ohm →基本介电强度 Dielectric strength of function500V →情况温度 Ambient temperature-25℃~125℃ →阻燃品级 FlammabilityUL94V-0 →适用于II类防护器具 Suitable for appliances of protection class II
