产品描述Product description
◆JB17系列是一款专用型的滑动开关，也叫推拉开关或推拨开关，集成防尘功效，适用于小型的电动工具，如：砂光机、100mm和125mm角磨机等。
◆JB17?series are one special type slide switches,?integratd dustproof, special for low Rated portable Power-tools, such as: Orbit Sanders, 100mm and 125mm Small Angle Grinders, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→单极�？� Single Pole Single Throw (SPST)
→单极双掷 Single Pole Double Throw (SPDT)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V36A
→最大攻击电流 Max. Inrush current at 127V60A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Diele ctric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals
→线路板焊接端子 PCB Solder terminals
电气参数和认证 Electric Rating and Certification
