产品描述Product description
◆K1-6C系列是一款标准型的小型跷板开关，也通称船型开关、波形开关等，可选带防护罩实现防尘和防水功效，用途极广，广泛应用于种种家用电器及办公设备，如：台灯、电扇、打印机、游戏机、电脑电源、有源音箱、饮水机等等 。
◆K1-6C?series are one standard type rocker switch, optional with?Protection Cap?for?dustproof?and?waterproof, commonly for use in small Home appliances and office equipments, such as Reading Lamps Electric Fans, Printers, Game Players, Computer P ower-supplys, Power Sound Box, etc.
产品特征Features
◆可选带以下功效 Optional with the function as follows:
→双极单掷?DPST (Double Pole Single Throw)
→双极双掷?DPDT?(Double Pole Double Throw)
→双极双掷带中间断开 DPDT with Centre-off
→点动功效 Momentary act
◆可选带以下附件 Optional with the accessories as follows:
→防护罩 Protection Cap
→焊接带端子导线 Soldering with leads and terminals
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V48A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~85°C
→操动件温度Actuator temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals 4.8×0.8mm
电气参数和认证 Electric Rating and Certification
